35K Ultrasonic Plastic Welding Machine
In ultrasonic welding, high frequency (15 kHz to 40 kHz) low amplitude vibration is used to create heat by way of friction between the materials to be joined. The interface of the two parts is specially designed to concentrate the energy for the maximum weld strength. Ultrasonic can be used on almost all plastic material. It is the fastest heat sealing technology available.
Ultrasonic welding machine is the use of ultrasonic generator to convert low current frequency to high frequency AC, then the same frequency of mechanical vibration by ultrasonic transducer, Mechanical vibration transmitted to the ultrasonic welding joints by the amplitude modulator, the vibrational energy welding joints received transfer to the workpiece to be welded joint. In the region, the energy through friction converted into heat energy, to melt the plastic, After vibration stopped, maintain short-term pressure makes the weldment on artifacts in molecular link way solidification as a whole.
Ultrasonic welding machine can be used for welding, implanting, forming, riveting, spot welding, removaling, and sewing.
Parameter:
Model: HT-35K-T1
Voltage: AC220V
Frequency: 35KHZ
Power: 900W
Welding Diameter: 0-200mm
Dimension: 420*600*900MM
